In Pakistan’s diverse climate, understanding how solar panel efficiency changes under different environmental conditions is vital. For both residential and commercial installations, factors such as ambient temperature, shading, and dust accumulation play a significant role in determining how much solar energy is converted into electricity. This technical analysis examines the major climate-related elements influencing photovoltaic (PV) performance across Pakistan, with a focus on real-world performance and long-term durability.

Temperature Impact on Solar Panel Efficiency

The performance of PV modules is directly linked to operating temperature. While greater sunlight intensity generally boosts energy generation, excessive heat reduces efficiency. In Pakistan, module surfaces can reach over 50 °C during the summer, causing notable power losses. When panels operate at high temperatures, internal resistance increases, reducing voltage output and efficiency.

Most commercial crystalline silicon panels exhibit a temperature coefficient in the range of –0.3% to –0.5% per °C above standard testing conditions. This means for every degree rise in temperature, output drops accordingly. Given that many parts of Pakistan experience summer temperatures exceeding 40 °C, the power reduction can be significant. Adequate ventilation or raised mounting structures can help maintain airflow behind the panels, reducing heat buildup.

Installers in Pakistan often recommend selecting panels with lower temperature coefficients and designing systems that maximize airflow. In regions like Sindh and Punjab, rooftop systems tend to suffer more from heat stress, whereas installations in northern Pakistan maintain slightly higher efficiency due to cooler air and reduced ambient heat.

Effects of Shading and Orientation

Shading is one of the leading causes of performance loss in PV systems. Even a small shadow on one section of a panel can disrupt the entire circuit and significantly reduce output. In Pakistan’s high-irradiance environment, this loss becomes even more critical during peak sunlight hours.

Shading can result from nearby trees, buildings, dust accumulation, or poor system layout. Studies show that shading can cause efficiency losses of up to 30 % or more depending on the extent and duration. To minimise this, panels should be oriented toward the south and tilted according to the site’s latitude, typically around 30° for most parts of Pakistan. Proper alignment ensures the panels receive the maximum possible sunlight throughout the year.

Moreover, shading activates bypass diodes inside the modules, which isolate the shaded cells to prevent hot spots. However, this still reduces the string’s total output. Therefore, shading analysis before installation is critical. In urban settings such as Karachi or Lahore, rooftop obstructions and nearby buildings make careful layout design even more important.

Dust, Soiling, and Climate Effects

Dust accumulation or soiling is one of the most persistent challenges for solar energy systems in Pakistan. The country’s semi-arid and arid regions are prone to frequent dust storms and fine particulate matter that settle on module surfaces. Dust reduces the amount of sunlight reaching the solar cells and also increases surface temperature, further reducing efficiency.

A study in Pakistan observed a clear difference between clean and unclean panels: clean modules produced around 296 W, while dusty ones only delivered about 170 W under identical conditions. This highlights how even a thin layer of dust can cut production by nearly half.

Regions like Bahawalpur, Multan, and Quetta require frequent cleaning due to their dry, windy conditions. In contrast, coastal areas such as Karachi face humidity and salt exposure, which pose corrosion risks. Monsoon rains in the south can temporarily clean panels but may also cause water spots and debris accumulation.

Additionally, high humidity, storms, and extreme temperatures contribute to faster module aging. The combined effect of heat and dust accelerates degradation, reducing the expected lifetime energy yield. Using anti-soiling coatings, hydrophobic glass, and automated cleaning systems can help mitigate these challenges in large-scale installations.

Climate Variability and Local Conditions in Pakistan

Pakistan’s geography spans multiple climate zones, from humid coastal regions to arid deserts and cooler highlands, each presenting unique challenges for solar energy production. Ambient temperature, humidity, and wind all affect performance differently across the country.

In southern Pakistan, regions such as Sindh and southern Punjab experience extreme summer heat exceeding 45 °C. Module surfaces get even hotter, causing substantial efficiency loss. In these areas, natural ventilation, reflective roofs, and raised mounting structures are essential.

In desert regions, dust is a far greater concern than temperature. For example, at the Quaid-e-Azam Solar Park in Bahawalpur, engineers reported notable production losses due to heavy soiling and insufficient cleaning frequency. With limited access to water for manual washing, dry or mechanical cleaning methods have become more common.

Northern areas, including Gilgit-Baltistan and Khyber Pakhtunkhwa, offer cooler temperatures and higher altitude advantages that reduce thermal losses and improve performance consistency. However, snow accumulation in winter months requires periodic cleaning to maintain exposure.

Urban centers like Lahore and Karachi face different issues: smog, pollution, and high humidity. These factors reduce sunlight intensity and may increase corrosion risk in connectors and metal mounts. Because Pakistan’s solar potential varies so greatly, site-specific assessment is crucial before installation.

Practical Mitigation Measures

To maintain optimal solar performance under Pakistan’s climatic conditions, several technical and operational strategies are recommended. The most effective approach begins with system design, choosing modules suited to local temperatures, installing with proper tilt and orientation, and ensuring no shading throughout the year.

Regular maintenance and cleaning schedules should be established, especially in dusty environments. Monitoring systems that track energy generation can quickly identify drops in output, indicating soiling or shading problems. In partially shaded installations, using micro-inverters or power optimizers ensures that one shaded panel does not reduce the performance of an entire array.

For large-scale plants, especially in desert zones, adopting robotic or dry-cleaning technology can reduce operational costs while maintaining consistent efficiency. Installers should also consider seasonal tilt adjustments to maximize sunlight absorption during winter and summer months.

When designing solar systems in Pakistan, every local environmental variable, from heat to dust to humidity, must be accounted for. The goal is not only to achieve high initial efficiency but also to ensure long-term stability and durability under the country’s demanding climate conditions.
